• TOA A-2030DD Mixer Amplifier | 30W | 3 Mic & 2 AUX Inputs | 100V PA System

  The A-2030DD-EB is a high cost-performance mixer power amplifier suited for broadcasting paging or background music in schools, offices, shops, factories, mosques, churches and large rooms.



  • 3 microphone inputs, 2 AUX input and 1 recording output
  • DD-varieties with 2 phone jacks and 1 5-pin DIN input
  • D-varieties with 3 phone jacks
  • Speaker output of constant voltage distribution system (100 V)
  • Independent tone control of boost and cut type for both high and low frequency
  • MIC 1 with phantom power and mute function
  • Current limiter to prevent damage due to current overload
  • Excess heat limit to protect the transistor and power transformer
  • Available in 30 W, 60 W, 120 W and 240 W rated output

• Feature	Details
  Power Source	220 – 240 V AC, 50 / 60 Hz
  Rated Output	30 W
  Frequency Response	50 Hz – 20 kHz (±3 dB)
  Distortion	< 1 % (at 1 kHz, 1/3 rated output power)
  S/N Ratio	60 dB (or more)
  Number of Channels	1
  Connectable Microphones	3
  Inputs	MIC 1: -60dBV, 600 Ohm, balanced, 5-pin DIN equivalent, phantom power selectable, + 21V <br> Mic 2-3: -60dBV, 600 Ohm, balanced, phone jack <br> AUX 1-2: -20 dBV, 10 kOhm, unbalanced RCA pin jack <br> Control input Mute: via DIN jack
  Outputs	Speaker: balanced (floating) / Rec out: 0 dBV, 600 Ω, unbalanced, RCA Pin Jack
  Dimensions (W x H x D)	420 x 100.6 x 280.3 mm
  Finish	ABS resin, Steel plate, black

• Description	Downloads
  TOA A-2030DD 30W Digital Mixer Amplifiers Datasheet	Downloads
