Jbl Pro 8124 4-Inch Full-Range In-Ceiling Speaker

Description

• Description
• Specifications
• Downloads

• JBL 8124 | 4″ Full-Range In-Ceiling Loudspeaker with 6W Transformer

  4-inch, Full-range, In-Ceiling Loudspeaker
  The 8124 is a 4-inch, full-range, cost-effective loudspeaker for commercial applications. The 8124 features high-fidelity performance in an easy to install package. The system’s high sensitivity drivers deliver maximum sound levels using minimal amplifier power. With its contemporary grill design, 70V/100V taps and an open-back design, the 8100 series brings elegance and performance to basic commercial sound systems, or any application not requiring a backcan for installation.
  Features
  Clear, High-Fidelity Performance
  Dog-ears for easy retrofit installations
  High Sensitivity (93 dB, 1W, 1m) for Maximum Power Efficiency
  6W Transformer for use of 70V / 100V Distributed Lines

• Drivers	4 in (100 mm), Full-range Driver	Frequency Range	60 Hz – 18 kHz
  Sensitivity	93 dB (1 kHz – 8 kHz)	Coverage Angle	130° conical
  Transformer Taps	6W, 3W, 1.5W (0.75W at 70V only)	Input Connectors	Bare wires
  Dimensions (Diameter x Depth)	8.1 in (206 mm) x 3.5 in (89 mm)	Weight	2.5 lb (1.2 kg)
  Included Accessories	Sculpted Grille	Optional Accessories	MTC-8124C C-ring, MTC-Rail tile rails
  Power Rating	See transformer taps	Maximum SPL (1m)	101 dB ave. (top 70V/100V tap)
  Color	White	Baffle/Rim	Plastic
  Ceiling Cutout Size	175 mm diameter (6.9 in)	Plenum Usage	Not intended for use in return air plenums
  Backcan	No

• Description	Downloads
  JBL PRO 8124 4″ Full-range In-Ceiling Loudspeaker DataSheet	Download
  JBL PRO 8124 4″ Full-range In-Ceiling Loudspeaker Quick Start Guide	Download
