Crown Xls 1502 Drivecore 2 Dual-Channel Power Amplifier

Description

• Description
• Specifications
• Downloads

• Crown XLS DriveCore 2 Series Power Amplifier | 2400W, Class D, DSP, PureBand Crossover

  Meet the new XLS DriveCore™ 2 Series
  The next generation of XLS got a makeover with a sleek new look, a LCD display that is three times larger, and more DSP with higher capabilities. Like its predecessor, the new XLS is ultra-efficient with Crown’s patented DriveCore technology and can drive 2400W at 4Ω bridged with tons of headroom guaranteeing a clean, undistorted signal straight to your speakers. The XLS DriveCore 2 assures that you will be heard as you deliver a powerful, pure sound experience for any venue.
  – Class D amp with Crown’s ultra-efficient DriveCore technology weighs less than 11 lb
  – Higher DSP capabilities: More control; has band pass filter per channel
  – Increased lighting functionality; turn off all LED indicators except clip and thermal to reduce distraction in dark venues
  – Selectable input sensitivity; 1.4Vrms and .775Vrms options so that amp can be driven at full power
  – Set sleep mode after specified time without having to press a button
  – Security setting disables menu buttons; menu locked/unlocked by entering combination
  – System reset allows factory settings to be restored
  – Remote power trigger
  – Peakx™ Limiters provide maximum output while protecting your speakers
  – XLR, 1/4″, RCA inputs provide flexibility
  – Integrated PureBand™ Crossover System for better performance and control
  – Efficient forced-air fans prevent excessive thermal buildup

• Feature	Specification
  Sensitivity	1.4 Vrms
  Frequency Response	+0 dB, -1 dB
  Signal to Noise	> 103 dB (at 0.775 Vrms, 6 dB lower)
  Intermodulation Distortion	< 0.3%
  Damping Factor	> 200
  THD	< 0.5%
  Crosstalk	At 1 kHz: > 85 dB At 20 kHz: > 55 dB
  Dimensions	19″ (48.3 cm) × 3.5″ (8.9 cm) × 7.7″ (19.6 cm)
  Weight	8.6 lbs (3.9 kg)

• Description	Downloads
  Crown XLS 1502 DriveCore 2 Series Power Amplifier DataSheet	Download
