• Blackmagic Design Micro Studio Camera 4K G2 | CINSTUDMFT/UHD/MRG2



  Blackmagic Micro Studio Camera 4K G2 is an amazing, broadcast quality live production camera in a tiny body. The Four Thirds sensor has 13 stops of dynamic range, incredible low light performance and produces stunning Ultra HD images in all lighting conditions. 12G-SDI Micro BNC connectors support 10-bit uncompressed video up to 2160p60 and 2 channel audio on the output. The input supports tally, camera control, control of the built-in color corrector plus lens control, from an ATEM switcher. Or when using an ATEM Mini switcher, the HDMI connector will output 1080 and support all control features. Plus it’s even a Hollywood quality cinema camera because it can record Blackmagic RAW to external USB-C drives. With multiple mounting points, place Blackmagic Micro Studio Camera 4K G2 where no other camera will go!

• Blackmagic Micro Studio Camera 4K G2 Specs

  Feature	Details
  Camera Features
  Sensor Size	Four Thirds (17.78mm x 10mm)
  Lens Mount	Active MFT
  Lens Control	Iris, focus, zoom (compatible lenses)
  Dynamic Range	13 Stops
  Dual Native ISO	0 dB & 18 dB Gain
  Shooting Resolutions	Up to Ultra HD (3840 x 2160) at 60 fps
  Frame Rates	Up to 60 fps in Ultra HD
  Focus	Autofocus (compatible lenses)
  Mounting Options	1x 1/4″ (top), 3x 1/4″ (bottom)
  Connections
  SDI Video I/O	1x 12G-SDI In/Out (Micro BNC)
  HDMI Video Out	1x HDMI Type A (up to 1080p60)
  Audio In	1x 3.5mm Stereo (can be used for Timecode)
  SDI Audio Out	2 Channels Embedded in 3G/6G/12G-SDI
  HDMI Audio Out	2 Channels, 48 kHz, 24-bit
  Remote Control	Over SDI, HDMI, or USB Ethernet
  Computer Interface	1x USB-C 3.1 Gen 1 for external recording & focus/zoom control
  Media
  Media Slot	1x USB-C 3.1 Gen 1 for external Blackmagic RAW recording
  Media Format	ExFAT (Windows/Mac) or HFS+ (Mac)
  Codecs	Blackmagic RAW (various constant bitrate & constant quality options)
  Control
  Buttons	5 (Set, Up, Down, Menu, Power)
  External Control	Blackmagic Zoom/Focus Demand, Blackmagic Control Protocol, REST API
  Tally	1x Front Facing LED
  Software
  Included	Blackmagic Camera Setup (Mac/Windows)
  OS Compatibility	Mac 12.0 Monterey or later, Windows 10/11 (64-bit)
  Power
  Power Supply	1x External 12V DC 36W
  Power Input	1x 12V DC Locking Connector
  Power Usage	18 – 25 W
  Physical Specs
  Operating Temp	0° to 40° C (32° to 104° F)
  Storage Temp	-20° to 45° C (-4° to 113° F)
  Dimensions	Not specified
  Warranty	12 Month Limited Manufacturer’s Warranty
