Adastra 953.053Uk Dm-8 Digital Messaging Unit For Public Address Integration

Description

• Description
• Specifications

• Adastra DM-8 Digital Messaging Unit




  Adastra DM-8 Digital Messaging Unit
  1U rack-mount digital messaging unit for scheduled audio playback. Audio files are stored on a removable SD card and may be transferred by inserting into a PC or Mac computer or directly recorded o…
  Up to 99 audio tracks stored on SD card.
  Up to 99 schedule events stored on SD card.
  Schedule file editable via PC/Mac.



  Product Description
  1U rack-mount digital messaging unit for scheduled audio playback. Audio files are stored on a removable SD card and may be transferred by inserting into a PC or Mac computer or directly recorded on the DM-8. Schedules are also stored on the SD media as a separate file, which can be edited with a computer and stored for backup. Separate SD cards may be saved with different audio messages and schedules and swapped for different routines. A mic/line input can be used for recording or for live announcements which can override SD playback. A BGM line input is provided for background music playback with its own level control and is muted when messages are playing or during paging. Up to 99 schedules can be programmed to play a particular audio file from the SD card, set by 24 hour time and day(s) of the week. The DM-8 can be added to any sound system to provide automated playback of timed announcements, music or audio alerts.
  Up to 99 audio tracks stored on SD card.
  Up to 99 schedule events stored on SD card.
  Schedule file editable via PC/Mac.
  Mic/Line input for recording or live announcements.
  BGM line input for background music.

• Feature	Details
  Power Supply	100-240Vac, 50/60Hz or 24Vdc
  Fuse	T1AL 250V
  Battery	CR2016 button cell (internal clock)
  Inputs	Paging mic/line (XLR or terminals), BGM (RCA)
  Output	Mono balanced terminal or unbalanced RCA
  Audio Source	Internal SD card player
  Time Setting	99 programmable schedules – 24 hour + day(s) setting
  Mic/Line Channel Controls	Mic/Line level, Phantom power on/off
  Phantom Power	+20V
  Input Impedance	2.2k Ohms (mic/line)
  Controls	Page/Rec, Mic, Clock Set, Schedule, Message 1-8, Output, Power on/off
  Trigger	Message 1-8, Stop & Ground contacts
  SD Card Requirements	4-32GB FAT32 (full size or with adaptor)
  Dimensions (W×H×D)	483 x 150 x 44mm
  Weight	1.65kg
  In the Box	DM-8 digital messaging unit, IEC mains lead(s)
