Viewsonic Ldc031-120 31 Inch P1.2 Ultra-Fine-Pitch All-In-One Led Display

Description

• Description
• Specifications
• Downloads

• Customizable P1.2 All-in-One LED Display for Dynamic Digital Signage

  The ViewSonic LDC series is an innovative, customizable All-in-One LED display that offers flexible sizing and effortless installation—all in a single solution. Combine the LDC031-120 LED cabinet to create video walls in diverse aspect ratios and sizes, delivering compelling digital signage that brings your concepts to life. Its all-in-one design ensures a hassle-free installation process and intuitive operation. Using Glue-on-Board (GOB) surface treatment technology, the IP54-rated LED modules provide enhanced protection against collision, dust, and moisture — making it ideal for public spaces such as lobbies, shopping malls, and transportation hubs. With its slim 31mm thickness and a control box that can be detached to achieve a 99% screen-to-body ratio, this premium display offers an exceptional viewing experience with sleek aesthetics. Complete with centralized management through LAN connectivity to enhance operational efficiency.

  Shaping Innovation
  LDC Series Customizable All-in-One LED Displays

  Craft Your Vision Effortlessly

  Embrace the Novel
  Customizable All-in-One LED Display
  Harmonizing All-in-One and traditional LED display technologies, the LDC series innovatively enables custom, large-format LED displays in various shapes and sizes. This ensures effortless installation and ease of operation, delivering vibrant visuals for an enhanced viewing experience in business, commercial, and public spaces.


  Display Sizes Tailored to Your Needs
  Draw in any audience and make a lasting impression with a display customized to your space and vision. Create striking vertical, ultra-wide, or unique configurations, enthralling viewers in various settings, from reception halls to malls, transportation hubs, and ballrooms.


  All-in-One Integration for Effortless Installation
  The LDC series enhances traditional LED displays by integrating power supply, control, image stitching, and display systems. This eliminates the complexity of configuring multiple systems and components, saving valuable time and effort. Simply switch on the display, and it’s ready to use.

  Flexible Installation with Two Control Box Options
  The LDC Series Control Box is available in two configurations to suit different installation needs.The Rack-Mount All-in-One System Control Boxis designed for professional AV environments, seamlessly integrating into 4U-compatible rack cabinets to provide centralized control. For meeting rooms, classrooms, and lecture halls, the Standard All-in-One Control Box offers a user-friendly solution with built-in speakers, accessible I/O ports, and a keypad for convenient power control, HDMI switching, and audio management.


  Detachable System Control Box for a Minimalistic Appearance
  The LDC series features a detachable control box, enabling an impressive 99% screen-to-body ratio for a premium, minimalist design that seamlessly integrates with any decor. For enhanced convenience, the control box can be positioned up to 10 meters away from the display, ensuring easy access to controls even in hard-to-reach installations.


  Mesmerize in Every Space

  Lobby


  Store Entrance


  Shopping Mall


  Transportation


  Car Show Room


  Banquet Hall


  Broadcasting


  Control Room


  Meeting Room


  Auditorium

  Reliable Operation & Efficient Management

  Enhanced Durability with Advanced GOB Surface Treatment
  Crafted for exceptional durability, this display features Glue-on-Board (GOB) surface treatment technology—a protective process that seals the LED module surface with transparent epoxy glue, enhancing protection during installation and use. Achieving an IP54* rating, it provides resistance against collisions, dust, and moisture, making it an ideal choice for public spaces such as lobbies, shopping malls, and transportation hubs.



  Centralized Management via LAN Control
  This display is compatible with Crestron and myViewBoard Manager, enabling easy and efficient management of multiple-display configurations from a PC via LAN connectivity.


  Seamless Collaboration with Split-Screen Modes
  Enhance collaborative content sharing with intuitive split-screen capabilities. This LED display seamlessly supports Picture-by-Picture (up to 4 different inputs) and Picture-in-Picture (a smaller screen within the main display) scenarios in real time, crafting a dynamic and versatile collaboration experience.


  Easy Full Front Maintenance
  Enjoy maintenance convenience with hot-swappable front LED modules, enabling effortless replacement of defective parts without relocating the entire display. The user-friendly magnetic suction tool ensures a hassle-free process, accessible to all, regardless of technical expertise.

  Stellar Audiovisual Impression


  Premium Aesthetics with Ultra-Slim & Bezel-Free Design
  Immerse yourself in stunning visuals with the premium, sleek, frameless display of the LDC series. Featuring a 31mm ultra-slim design and 6mm ultra-thin bezels, it exudes sophistication while effortlessly complementing any interior style. Ideal for corporate lobbies, flagship stores, or reception rooms, it’s designed to impress audiences across diverse settings.


  Captivating Visuals that Shine Bright
  Celebrate brilliant clarity with a high brightness of 600 nits along with 100-level adjustments and a remarkable 6,500:1 contrast ratio. This display guarantees captivating, clear visuals even in large venues with ambient lighting, like shopping malls or hotel ballrooms. Boasting a lightning-fast 3,840 Hz refresh rate, it effortlessly captures attention and enhances your brand image with superior visual impact.


  Engage Your Audience through Powerful Audio
  Deliver compelling presentations that captivate your audience with the display’s dual sets of 30W speakers, ensuring powerful and clear sound.

  Dimensions & I/O Ports


  1.USB 2.0
  2.Power Kry + LED Indicator
  3.Cabinet LAN Cable x18
  4.HDMI 2.0 Output x2
  5.DP 1.2 Output
  6.DP 1.2 Input
  7.HDMI 2.0 Input x3
  8.Optical
  9.IR Extended
  10.Audio Out
  11.Internet
  12.Service
  13.RS-232
  14.USV 2.0 x2
  15.Power Switch
  16.LAN Control
  17.Service
  18.AC Out x4
  19.AC In x2


  1.Speakers
  2.HDMI Out
  3.SPDIF Out
  4.HDMI In x4
  5.LAN
  6.Audio Out x2
  7.IR Interface
  8.Light Senor
  9.IR Receiver
  10.USB-C
  11.USB-A 3.0
  12.USB-A 2.0
  13.Menu Control:Setting
  14.Menu Control:Enter
  15.Menu Control:Brightness Level
  16.Power Button
  17.Indicator Light

• Specification
  Screen Size	31.5″	Panel Technology	Direct view LED
  LED Package Type	IMD 2 in 1 (GOB)	Bonding Wire	Copper
  Pixel Pitch (mm)	1.25	Brightness (max.)	600 nits (100 levels adjustable)
  Contrast Ratio (typ.)	6500:1	Color Temperature	3000K -10000K
  Orientation	Landscape	Viewing Angles (typ.)	H = 170, V = 170
  LED Lifetime (typ.)	100,000 Hours	Local Storage	Total 32GB (26GB available storage)
  Embedded OS	Android 9.0	Resolution Support	VGA(640 x 480) to 4K(3840 x 2160@60hz)
  HDTV Compatibility	480p, 576p, 720p, 1080p, 2160p	Horizontal Frequency	31K-94kHz
  Vertical Scan Rate	56-85Hz
  Input
  HDMI	4 (HDMI 2.0/HDCP 2.2) (internal x3, external x1)	USB Type A	3 (USB3.0 x1, USB2.0 x2)
  RJ45 Input	3 (internet x2, control x1)	IR in (3.5mm)	1
  Wi-Fi Input	2.4G/5G Hz	USB Type C	1 (data only)
  Output
  HDMI out	1 (HDMI 1.4/HDCP 1.4) (internal x1)	Speaker	30Wx2
  Audio out (3.5mm)	2	S/PDIF	1
  USB Type A (Power)	Shared with USB A input (USB 3.0 5V/0.9A x1, USB 2.0 5V/0.5A x1, USB 2.0 5V/2A x1)	USB Type C (Power)	Shared with USB Type C input (5V/1A x1)
  Control
  RJ45 (LAN control)	1(shared with internet)	USB Type A (Services)	1(shared with USB A input)
  RS232 (DB 9-pin female)	1	IR Receiver	1
  Light Sensor	1
  Others
  Power Supply Voltage	100-240V ~ 50/60Hz (vary by country)	Power Consumption (W/unit)	48W per cabinet (typ), 145W per cabinet (max), < 0.5W (Hibernate)
  Power Consumption (W/m²)	156W/m² (typ), 472W/m² (max)	Operating Temperature	0~40℃
  Total LED Module Quantity	6 per cabinet	Ingress Protection Rating	IP54(Front)
  Impact Protection Rating	IK06(Front)	Net Weight	13.89 lbs (6.3kg) per cabinet
  Standard Accessories
  Control Box	LD-SCB-023	Power Cord	By Configuration
  LAN Cable (Cat 5E)	1	IR Extender Cable	1
  Remote Control	1	Installation Guide	1
  Wall Mount	1	Spare Parts	LED module 7% 3 in 1 hub board x1
  Maintenance Tool	LD-MK-004 x1 LD-MK-006 x1
  Optional Accessories
  Control Box	LD-SCB-011 LD-SCB-021	Maintenance Tool	LD-MK-004 LD-MK-006
  Floor Stand	LD-STND-009 (support 4×3/4×4/5×3/5×4/6×3/6×4)
