Ubiquiti 25G Sfp28 Lr Transceiver – Long-Range Fiber Optic Module

Description

• Description
• Specifications

• Ubiquiti Network Transceiver Module Fiber Optic 25000 Mbit/s




  The UACC-OM-SFP28-LR is a 25 Gbps Multi-mode Optical Module is an optical transceiver capable of sustaining 25 Gbps throughput over a ber connection. After connecting the module to a compatible ber line, simply insertitinto any SFP28 portto experience true 25 Gbps speed.

  Ubiquiti Optical Module SFP28 25Gbps Key Features
  25 Gbps throughput
  SFP28-compatible
  Designed for cable deployments spanning up to 100 m

• Technical Specifications	UACC-OM-SFP28-LR
  Supported Media	Single-mode fiber
  Connector Type	(2) LC
  TX Wavelength	Blue latch: 1310 nm
  RX Wavelength	Blue latch: 1310 nm
  Data Rate	25 Gbps
  Max. Power Consumption	1.3W
  Cable Distance	10 km
  Ambient Operating Temperature	0 to 70° C (32 to 158° F)
  WARNING	CLASS 1 LASER PRODUCT, IEC/EN 60825-1:2014 – Do not look into the ends of the fiber optic cable or SFP module while converters are powered.
