Trantec S4.04 Lapel Wireless Microphone System (S4.04-L-Eb-Gd5)

Description

• Description
• Specifications

• Trantec S4.04-L-EB GD5 Lapel Microphone System | 4 Frequencies, PLL Quartz, 10h Battery

  The Trantec S4.04-L-EB GD5 Lapel microphone system contains a beltpack transmitter and a lapel microphone. Available on channel 70 with 4 switchable licence free frequencies and fully synthesized PLL quartz tuning technology.

• Component	Specification
  Diversity Reception	Antenna Diversity
  Sensitivity	10µV at 45dBA, S/N
  Squelch	Tone SQ, Carrier SQ, Noise SQ
  Audio Frequency Response	50Hz – 15kHz
  Audio Output Level (Max.)	Balanced (XLR): -20dBu, Unbalanced (1/4″ Jack): 10dBu
  Power Supply	12 VDC, 500mA
  Dimensions	215(W) x 39(H) x 102(D) mm
  Weight	480 g
  RF Carrier Power	10 mW
  Audio Frequency Response	50Hz – 15kHz
  Audio Input Level	-6dBV (max), mic gain 0dB
  Battery Life	Approx. 10 hours
  Power Supply	1 x AA battery (1.5V)
  Finish	Resin, coating
  Dimensions	62(W) x 100(H) x 25(D) mm
  Weight	85 g (with battery)
