• TOA SC-615M | 15W Compact Weatherproof Horn Speaker for PA Systems



  Horn Speakers
  The SC-615M is a compact, highly intelligible speaker suited to public address announcement applications. Its external speaker component finished with powder coating, and stainless steel bracket and screws ensure the unit’s weatherproof capability.
  Very rugged speaker with durable construction ensures long term reliable operation
  High quality sound
  High SPL
  Easy impedance selection through switch
  High impedance 100 V line
  Shock resistant oval horn

• Category	Specification	Description
  Frequency response	280 Hz – 12.5 kHz	Covers a wide frequency range
  Sensitivity (1 W, 1 m)	112 dB	High sensitivity for loud sound output
  Rated input (100 V)	15 W	Power handling capability
  Tappings	100V LINE: 670Ω (15W), 1kΩ (10W), 2kΩ (5W), 3.3kΩ (3W) 70V LINE: 330Ω (15W), 670Ω (7.5W), 1kΩ (5W), 2kΩ (2.5W), 3.3kΩ (1.5W)	Various power tap settings for flexible use
  Operating temperature	-20 °C to +55 °C	Suitable for a wide range of temperatures
  Finish	Aluminium, off-white (RAL 9010 or equivalent)	Durable and weather-resistant construction
  Dimensions	222 x 179 x 234 mm (W x H x D)	Compact size
  Weight	1.3 kg	Lightweight for easy installation

• Description	Downloads
  TOA Wired 15 W Horn Speakers | SC-615M DataSheet	Downloads
