• TOA Wired 15 W Ceiling Loudspeaker White




  Ceiling Speakers
  Integrated with a speaker unit and panel, the PC-2852 Ceiling Mount Speaker is of all metallic construction and ideal for use in a voice alarm system. It feature spring clamp mechanism for easy speaker mounting to the ceiling. The input impedance can be easily changed by changing the tap position of the transformer. The push-in type input terminal block makes cable connections easy and allows bridge wiring.
  Features
  20 cm speaker
  Rated input 15 W
  Very high sound pressure level
  For paging and BGM
  Easy installation with spring catches
  Push-in terminals
  Bridge wiring

• Category	Specification	Description
  Frequency Response	45 Hz – 20 kHz	Wide frequency range for versatile sound output.
  Sensitivity	96 dB (1 W, 1 m)	High sensitivity for clear audio at lower power.
  Rated Input	15 W (100 V)	Power handling capability of the speaker.
  Tappings	15 / 10 / 5 / 3 W (100 V), 15 / 7.5 / 5 / 2.5 / 1.5 W (70 V)	Multiple power settings for flexible use.
  Speaker Component	20 cm coaxial cone-type	Provides balanced sound with good dispersion.
  Finish	Steel plate, traffic white (RAL 9016)	Durable finish in a standard color.
  Dimensions	280 x 93 mm (Ø x D)	Compact size for easy integration.
  Weight	1.6 kg	Lightweight for convenient installation.

• Description	Downloads
  TOA Wired 15 W Loudspeaker White | PC-2852 DataSheet	Downloads
