Toa A-2060Dd 60W Digital Mixer Amplifier For 100V Line Systems

Description

• Description
• Specifications
• Downloads

• TOA A-2060DD Digital Mixer Amplifier | 60W, 3 Mic Inputs, Phantom Power, 100V Output

  A-2060DD
  Digital Mixer Amplifiers

  The A-2060DD-EB is a high cost-performance mixer power amplifier suited for broadcasting paging or background music in schools, offices, shops, factories, mosques, churches and large rooms.

  • 3 microphone inputs, 2 AUX input and 1 recording output
  • DD-varieties with 2 phone jacks and 1 5-pin DIN input
  • D-varieties with 3 phone jacks
  • Speaker output of constant voltage distribution system (100 V)
  • Independent tone control of boost and cut type for both high and low frequency
  • MIC 1 with phantom power and mute function
  • Current limiter to prevent damage due to current overload
  • Excess heat limit to protect the transistor and power transformer
  • Available in 30 W, 60 W, 120 W and 240 W rated output

• Feature	Specification
  Weight	4.6 Kg
  Dimensions (W x D x H)	420 x 100.6 x 280.3 mm

• A-2060DD : Datasheet
