Startech Sdi2Hd Converter: 3G-Sdi To Hdmi With Loop-Through Functionality

Description

• Description
• Specifications
• Downloads

• Startech SDI2HD SDI to HDMI Converter – 3G SDI to HDMI Adapter with SDI Loop Through Output

  The SDI2HD 3G SDI to HDMI converter enables you to turn a 3G SDI video signal into an HDMI video output. The adapter features a built-in 3G SDI daisy chain port, giving you the ability to further extend the SDI source to up to 755ft (230m) over standard coaxial cable, for large scale HD-SDI video broadcasting distribution.



  To ensure you maintain perfect high-definition video quality the SDI-HDMI converter features supports resolutions up to 1080p, allowing you to convert SDI to HDMI without sacrificing video quality.
  For hassle-free installation, the SDI to HDMI converter offers a plug-and-play solution that includes pre-installed mounting brackets and requires no software or driver installation.
  The SDI2HD is backed by a StarTech.com 2-year warranty and free lifetime technical support.
  Applications
  Convert a 3G SDI video run to HDMI from up to 755ft (300m) away
  Connect your HDMI display to a 3G SDI video run
  Output to an HDMI Display and continue your 3G SDI run up to an additonal 755ft (300m) using the daisy chain port
  The StarTech.com Advantage
  Increase scalability, with built-in 3G SDI daisy chain port
  Maintain High-definition video quality while converting from 3G SDI to HDMI, with support for resolutions up to 1080p
  Hassle-free installation, with pre-installed mounting brackets and no software or drivers required

• Category	Attribute
  Warranty	2 Years
  Connector A	1 x SDI (BNC)
  Connector B	1 x HDMI (19 pin)
  Operating Temp	0°C to 70°C
  Storage Temp	-10°C to 80°C
  Humidity	5% to 90% RH
  Adapter Type	Active
  AV Input	SDI (BNC)
  AV Output	HDMI
  Ports	1
  Cabling	Coaxial
  Audio Support	Yes
  Rack-Mountable	Yes
  Chipset ID	Gennum – GV7600
  Daisy-Chain	Yes
  Max Data Rate	2.97 Gbps
  Max Cable Length	230 m
  Max Resolution	1080p
  Supported Resolutions	1080p/i, 720p @ 24–60 FPS
  Wide Screen	Yes
  SD Formats	525i & 625i
  Video Formats	8/10-bit RGB/YUV
  Product Weight	207 g
  Color	Black
  Material	Steel
  Dimensions (LxWxH)	11.2 x 6.5 x 2.5 cm
  Power Source	AC Adapter Included
  Input Voltage	100 – 240 AC
  Output Voltage	5 DC
  Output Current	2 A
  Power (Max)	10 W
  Included Items	Adapter, Mount, PSU, Manual

• Description	Downloads
  Startech SDI2HD SDI to HDMI Converter – 3G SDI to HDMI Adapter with SDI Loop Through Output DataSheet	Downloads
  Startech SDI2HD SDI to HDMI Converter – 3G SDI to HDMI Adapter with SDI Loop Through Output Instruction Manual	Downloads
