• Startech 2-Port HDMI 2.1 Switch 8K@60Hz HDR10+ Auto & Manual Switching | 2PORT-HDMI-SWITCH-8K

  This 2-Port HDMI Video Switch enables two HDMI sources to connect to a single HDMI input on a display.



  8K 60Hz Resolution
  The HDMI Switcher supports resolutions of up to 8K 60Hz. In addition, it supports lower resolutions at higher refresh rates, such as 4K 144Hz, 4K 120Hz, and 1080p 240Hz.

  This Video Switch is HDMI 2.1 complaint and supports features such as Variable Refresh Rate (VRR), Auto Low-Latency Mode (ALLM), and Consumer Electronics Control (CEC). It is backwards compatible with HDMI 2.0 (and lower) devices.

  Automatic or Manual Operation
  The 8K Video Switch features three options for selecting the source device. Automatic mode detects and selects the most recently activated source device or it will revert to the last active source device. Manual mode selects the desired port, using the push buttons, or with the included remote control (batteries not included). The remote control can enable or disable the automatic switching mode and it can disable the IR functionality.

  Flexible Installation Options
  Use the included USB wall charger and 2.5ft (78cm) USB Micro-B cable to power the unit. If a wall outlet is unavailable, the 8K Switch can be powered through a 5V 1A USB port as well.

  The included mounting kit and rubber feet enable versatile installation options. The metal housing enhances durability, making it suitable for installation and use in a variety of environments.

  This product is backed for 2-years by StarTech.com, including free 24/5 multi-lingual technical assistance.

  Applications
  Use in digital signage applications to display multiple 8K 60Hz source devices at different times
  Ideal for a presentation room setting, enabling users to plug in and automatically switch to the new device
  Connect more source devices to an HDMI display

• Category	Details
  Warranty	2 Years
  Inputs	2 x HDMI, 1 x USB Micro-B (Power)
  Output	1 x HDMI
  AV Input/Output	HDMI / HDMI
  Audio Support	HDMI 7.1 Channel Audio
  Indicators	Power, Port, Auto Switch, IR Mode LEDs
  Max Cable Distance	5 m (16.4 ft)
  Supported Resolutions	8K 60Hz, 4K 144Hz/120Hz/60Hz, 5120×1440, 1080p
  Wide Screen Support	Yes
  Material	Metal
  Color	Black
  Product Size	9 x 4.4 x 1.4 cm (3.5 x 1.7 x 0.6 in)
  Product Weight	87 g (3.1 oz)
  Power Source	USB Wall Charger Included
  Input Voltage	100 – 240V AC
  Output Voltage	5V DC
  Output Current	1A
  Power Use	5W
  Driver Requirement	No Drivers/Software Needed
  Note	HDMI 2.1a cables required for full performance
  In the Box	Switch, Remote, Mount Kit, Charger, Cable, Guide
