• StarTech 2-Port Gigabit Midspan PoE+ Injector, 10/100/1000Mbps, PoE+ (802.3af/at), 30W | AF221CE-POE-INJECTOR

  This 2-port multi-speed PoE+ injector serves as Power Sourcing Equipment (PSE) and enables Ethernet speeds of 10/100/1000Mbps. This mid-span inline injector can transmit network data and power up to 328ft (100m) for two Powered Devices (PD).

  Versatile PoE Injector

  Dual-port PoE injector supports the IEEE 802.3af and IEEE 802.3at PSE standards and delivers up to 30W output (52V/0.580A). Connect a remote PoE device to a network at a location where there is no power source, but an Ethernet cable already exists. This includes access points, IP cameras, VoIP phone systems, IPTV and access controls. The flexible design allows for either desktop or surface-mount use.



  Streamlined Cable Management

  All Ethernet cables can be routed from one side of the unit for efficient and organized cable management. The compact design (3.2x1x1.8in(82x25x46mm) ensures straightforward integration into existing network infrastructure, saving space and time during installation.

• Category	Details
  Warranty Information	Warranty: 2 Years
  Connector(s)	Connector A: 1 – RJ-45 (PoE+) Connector B: 1 – RJ-45
  Environmental	Operating Temperature: 0°C – 60°C (32°F – 140°F) Storage Temperature: ‐10°C – 70°C (14°F – 158°F) Humidity: 5% – 90% RH (non-condensing)
  Hardware	Ports: 2 Industry Standards: IEEE 802.3at Type 2 / PoE+ (30 W), IEEE 802.3af Type 1 / PoE (15.4 W), IEEE 802.3ab (1000BASE-T), IEEE 802.3u (100BASE-TX), IEEE 802.3i (10BASE-T), IEC 61000-4-2 Level-4 ESD protection (8kV contact/15kV air)
  Chipset ID	IC Plus – IP802AR
  Indicators	LED Indicator: 1 – Solid Green (Power) PoE Indicator: Solid Green (Supplying PoE)
  Packaging Information	Package Height: 3.8 cm [1.5 in] Package Length: 14.4 cm [5.7 in] Shipping Weight: 105.0 g [3.7 oz] Package Width: 20.7 cm [8.1 in] Package Quantity: 1
  Performance	Wake On LAN: Yes Max Data Transfer Rate: 1000 Mbps Max Cable Length: 100 m [328.0 ft] ESD Protection: +/-8kV (Contact), +/-15kV (Air) Compatible Networks: 10/100/1000 Mbps Auto MDIX: Yes PXE: Yes Jumbo Frame Support: 9K max.
  Supported Protocols	Wake-on-LAN (WoL)
  Physical Characteristics	Color: Black Height: 2.5 cm [1.0 in] Length: 10.2 cm [4.0 in] Weight: 60.0 g [2.1 oz] Width: 4.6 cm [1.8 in] Material: Plastic
  Power	Power Source: AC Adapter Included Input Voltage: 100 – 240 AC Input Current: 1.5 Output Voltage: 52 DC Output Current: 1.25 Center Tip Polarity: Positive Plug Type: M Power Consumption: 65W
  Software	OS Compatibility: No drivers or software required
  What’s in the Box	Included: 1 – PoE Injector 1 – EU/UK Power Adapter 1 – Quick-Start Guide

• Description	Downloads
  Datasheet	Download
  Manual	Download
