• Panasonic 0.280-0.299:1 Ultra Short Throw Lens




  Superior Flexibility for Easy Installation
  Conventional ultra-short-throw lenses demand accurate, time-consuming projector installation positioning with no margin for error. The ET-DLE020’s optical zoom, however, provides an installation margin of ±45 mm (±1.77˝) and easy image adjustment at a throw-ratio of 0.280:1, all with zero image offset. Combines with Panasonic laser projectors*1 to support Wide-range Vertical and Horizontal Lens-Shift, more than doubling movable shift area of comparable lenses, increasing installation flexibility, and expediting setup.
  High Reliability for Continuous Operation
  The ET-DLE020 features an aspherical all-glass lens that’s heat- and scratch-resistant. Durable construction enhances reliability for long-term use, and when combined with our dust-resistant laser projectors*, assures consistently brilliant images under continuous operation.
  * Please refer to the specifications page to check projectors compatible with ET-DLE020.
  On-Axis Rear Projection
  The ET-DLE020’s straight mirrorless design makes screen-centered projector installation possible in rear-projection applications.
  Note: Hot spots may occur depending on the screen.
  Zero Offset and Flexible Setup for Multi-Screen Projection
  Install your Panasonic 1-Chip DLP™ laser projector on-ceiling and close to the wall for full top-to-bottom screen coverage with zero offset and minimal shadowing, even in low-ceiling applications. Zoom and wide-range V/H Lens Shift joins flexible edge-blending adjustment for multi-screen projection.

• Specification	Details
  Lens Type	Ultra-Short-Throw Zoom Lens
  Throw Ratio	XGA: 0.290 – 0.309:1 WXGA: 0.294 – 0.314:1 WUXGA: 0.280 – 0.299:1 4K: 0.279 – 0.297:1
  F Value	2.0
  Focal Length	4.1 – 4.4 mm (5/32 – 11/64 inches)
  Screen Size	100 – 400 inches
  Dimensions (W x H x D)	170 x 170 x 391 mm
  Lens Weight	Approx. 3.2 kg
  Compatible Projectors	PT-RQ7L, PT-RQ6L, PT-RZ7L, PT-RZ6L PT-RCQ10, PT-RCQ80, PT-RZ120, PT-RZ990 PT-RZ890, PT-RZ790, PT-RZ690, PT-RZ970 PT-RW930, PT-RX110, PT-RZ870, PT-RZ770 PT-RW730, PT-RZ660, PT-RW620
