8-Port PoE+ Gigabit Smart Switch with 2 SFP Uplinks
Small, Yet Powerful Gigabit Smart Switch Packed with Advanced Features
Joining the NETGEAR® ProSAFE® family of Smart Managed Switches with high performance and cost efficiency, this 10-port Gigabit Smart Managed Switch is packed with powerful L2 features capable of enhancing any type of business network. The GS110TP is designed for customers who need a low port density solution with the combination of Gigabit speed and PoE capability. The GS110TP comes with 8 dedicated 10/100/1000 Mbps copper ports to connect to your end devices and two additional Gigabit Fiber ports for uplinks with greater distance. With PoE capability on all 8 copper ports, the GS110TP can automatically detect PoE on the end devices and dynamically manage power assignments and priority. It is capable of delivering up to 15.4W of power per port, up to a maximum total of 46W across all connected PoE devices, and network connectivity concurrently across a single ethernet cable, to power devices such as wireless access points, IP phones and IP cameras, providing flexibility and ease of deployment to your network.
The GS110TP comes with a comprehensive set of features, such as enhanced VLAN and QoS, access control lists (ACL), 802.1x port authentication (MD5), rate limiting and IGMP snooping and many more, to provide businesses with networks that are geared for growth while ensuring performance and reliability. Both an intuitive Web-browser GUI interface and Smart Control Center (Windows PC required), offer simple Smart Managed Switch management, making it a snap to monitor switch performance, configure ports, even set up port trunks, VLANs, and traffic prioritization.
With the fanless design and compact form factor, the GS110TP offers quiet operation and is suitable for deployments in any type of environment, especially the ones which are sensitive to noise. -
Category Attribute Value General Information Product Type Ethernet Switch Part Number GS110TP-300EUS Website http://www.netgear.co.uk Manufacturer Netgear, Inc Product Model GS110TPv3 Product Name ProSafe GS110TPv3 Ethernet Switch Product Line ProSafe Brand Name Netgear Management & Protocols Manageable Yes Network & Communication Layer Supported 3 Power Description Power Source Power Adapter Miscellaneous Country of Origin China Environmentally Friendly Yes I/O Expansions Expansion Slot Type SFP (mini-GBIC) Number of SFP Slots 2 Total Expansion Slots 2 Interfaces/Ports Modular Yes Uplink Port Yes Network Ports 8 Port Details 8 x Gigabit Ethernet PoE+ Expansion Slot Details 2 x Gigabit Ethernet Expansion Media & Performance Network Technology 1000Base-X, 10/100/1000Base-T Ethernet Technology Gigabit Ethernet Media Type Supported Optical Fiber, Twisted Pair Physical Characteristics Weight (Approx.) 610 g Form Factor Wall Mountable, Desktop Height 27 mm Width 236 mm Depth 101 mm -
Description Downloads Netgear ProSafe GS110TPv3 8 Ports Manageable Ethernet Switch DataSheet Downloads Netgear ProSafe GS110TPv3 8 Ports Manageable Ethernet Switch User Manual Downloads
