Netgear GSM4328PA-100NES | 24x1G PoE+ Managed Switch 480W with 2x10G & 2xSFP+
Business Continuity Management
Full-width switches offer dual redundant, modular power supplies (select m4300 models)
High Availability (HA)
Non-stop forwarding (NSF) virtual chassis architectures with hitless failover across the stack
Multi-Resiliency
Stacking and distributed link aggregation allow for zero downtime and load balancing capabilities
PVST+ Interoperability
Per VLAN Spanning Tree and Per VLAN Rapid Spanning Tree (PVSTP/PVRSTP)
Link Dependency
Enables or disables ports based on link state of different ports
Advanced IPv4/IPv6 security
Malicious code detection, DHCP Snooping, IP Source Guard protection and DoS attacks mitigation
Simple GUI
Full- functional Web console (GUI) for IT admins who prefer an intuitive graphical interface
Flexible & Efficient
Line-rate Spine and Leaf topologies offer many possibilities for server rooms, branch collapsed cores, or at the edge of growing networks.
Mix & Match Stacking
Stack between 10/40 Gigabit and 1 Gigabit models using any 10G/40G port, with any media type (RJ45, SFP+, DAC cables). Vertical, horizontal, manage as one unit
Room to Grow
With PoE+, plug and play ports, and hot swap, you’re ready to grow whenever you need to.
Industry Standard
SNMP, RMON, MIB, LLDP, AAA, sFlow, RSPAN and PTPv2 1-step transparent clock implementation (select M4300 models)
Zero Touch AV-over-IP
Pre-configured for Out-of-Box L2 Multicast (SDVoE-ready)
No Delay
Non-Blocking Fabric for Near-Zero Switch Latency
NETGEAR IGMP Plus™
Prevent network flooding with effortless multicast implementation of Layer 2 Multicast
Dedicated Design
ProAV Engineering Services for AV Network Design and Install Support ProAVDesign@NETGEAR.com
One Cord for All
Hot swap APS550W PSUs deliver 480W redundant PoE+ budget across 24 ports, or 720W in share mode
Industry-Standard
Management
Stay on top of operations with: CLI, local GUI,SNMP, sFlow, RSPAN, single pane of glass NMS300
Secure Your Data
Defend with Access Control, DiffServ QoS policies,LACP Link Aggregation, Private VLANs, Denial of service protection
Dependable Operations
Enjoy high availability across virtual servers through load balancing and nonstop forwarding failover. -
Technical Specs Specifications Table Sizes 128K MAC 8k ARP / NDP Throughput Up to 960 Gbps Throughput up to 714 Mpps Application Static Routing 64v4 / 64v6 RIP: 512 OSPF: 512 Latency 0.9µs 10G SFP+ 1.25µs 10G RJ45 IP Multicast 1,024 IPv4 / 512 IPv6 Multicast IGMP Membership 2k IPv4 / IPv6 M4300 Series features License-free L2 and Layer 3, Layer 4 with Policy Based Routing, RIP, VRRP, OSPF and PIM VLANs 4k with 2K DHCP Server Leases IPv4: 256 Pools / IPv6: 16 Pools Stackable Managed Switch Platform Mix-and-match Stackable Managed Switch Platform with nonstop forwarding and failover on all 1Gb to 10Gb models Pre-configured for AV-over-IP Pre-configured for AV-over-IP L2 Multicast on all models 10G models (SDVoE Ready) -
Description Downloads Netgear AV GSM4328PA-100NES 24x1G PoE+ 480W, 2x10G, 2xSFP+ Managed Switch Datasheet Downloads
