• NEC PA1505UL Professional Advanced LCD Laser Installation Projector

  A new class of bright projection
  Now even larger spaces can benefit from Sharp/NEC’s innovation in silent technology with the 15,000 center lumens PA1505UL laser projector, ensuring all attention is focused on the stunning image delivery.
  Featuring unprecedented White Point performance, factory pre-calibrated for the perfect white, 12-bit colour signal processing and wide colour space, the audience will experience extraordinarily vivid colour saturation and contrast levels.
  The enhanced sealed optical engine allows a filter-free design, IP5X rated against dust ingress – no possibility of dust contaminating the LCD panels for long-term picture stability and brilliant colour brightness. What’s more, with our filterless LCD projector design and no lamp replacement, service costs are dramatically reduced for a low cost of ownership and up to 20,000 hours life-time.
  Sharp/NEC customers can easily make the transition to benefit from the latest laser technology. The PA1505UL is a professional installation projector featuring advanced installation capabilities as demanded by higher education, leisure and museum applications.
  No lamp replacement – up to 20,000 h maintenance free operation possible due to Laser Light Source.
  No filter service required – the enhanced sealed optical laser LCD engine allows a filter-free design, IP5X rated against dust ingress. Brilliant colour brightness is maintained and servicing costs need no longer feature in your budget
  Compact design – a large venue projector with a comparatively small footprint and light weight design.
  Impress with vivid colour & contrast – brilliant white and wide colour space with high dynamic contrast supporting HDR10 standard via HDMI interface.
  Incredible visualisation capabilities – impressive free tilt and portrait installation capability, unique geometric adjustment, picture in picture, tiling and camera based blending.

• Category	Description
  Projection Technology	3LCD Technology
  Native Resolution	1920 x 1200 (WUXGA)
  Aspect Ratio	16:10
  Contrast Ratio	3000000:1
  Brightness	14000 Lm / 15000 Lm Center
  Lamp	Laser Light Source
  Light Source Life [hrs]	20000
  Lens	6 motorized lens options
  Lens Adjustment	Motorized
  Lens shift	Up to H:±25, V:+65,-65
  Keystone correction	+/- 40° manual horizontal / +/- 30° manual vertical
  Projection Factor	Depending on lens selection (std. option NP54ZL at 1.25-2.01:1)
  Projection Distance [m]	0.68 – 80.77
  Screen Size	Maximum: 1,270 cm / 500″; Minimum: 152 cm / 60″
  Zoom	Motorized
  Focus Adjustment	Motorized
  Supported Resolutions	1080i/50/60; 1080p/24/25/30/50/60; 1920×1200 (WUXGA) – 640×480 (VGA); 2048×1080 (2k); 2560×1600 (WQXGA); 4096×2160 (4k); 720p/50; 720p/60
  Frequency	Horizontal: analog: 0-0 kHz, digital: 15/24-153 kHz; Vertical: 24 – 120 Hz
  CONNECTIVITY
  Digital Input	1 x 3G-SDI; 1 x HDBaseT; 2 x HDMI™ supporting HDCP 2.2
  Digital Output	1 x HDBaseT supporting HDCP 2.2
  Audio Input	1 x HDBaseT audio support; 2 x HDMI audio support
  Audio Output	1 x 3.5 mm Stereo Mini Jack (variable)
  Control Input	1 x 3.5 mm Stereo Mini Jack (Wired Remote); 1 x D-Sub 9 pin (RS-232), Ethernet
  LAN	1 x RJ45
  USB	1 x Type A (USB 2.0 high speed)
  REMOTE CONTROL
  Remote Control	Audio Control; Digital Zoom; Geometric Correction; ID Select; ID set; Power (On-OFF); Select (up, down, left, right); Shutter function; Source Select; Test Picture; Zoom/Focus and Lens Shift Control
  ELECTRICAL
  Power Supply	100-240 V AC; 50 – 60 Hz
  Power Consumption [W]	925 Normal / 825 Silent Mode / 0.5 Network Stand-by / 2.0 Stand-by
  MECHANICAL
  Dimensions (W x H x D)	599 x 238 x 490 mm (without lens and feet)
  Weight [kg]	28.7
  Fan Noise [dB (A)]	38 / 35 (Normal / Silent)
  Colour Versions	Black; White
  ENVIRONMENTAL CONDITIONS
  Operating Temperature [°C]	0 to 40
  Operating Humidity [%]	20 to 80 non-condensing
  Storage Temperature [°C]	-10 to 50
  Storage Humidity [%]	20 to 80 non-condensing
  ERGONOMICS
  Safety and Ergonomics	CE; EAC; ErP; RoHS; TUEV Type Approved
  ADDITIONAL FEATURES	4K/60Hz interfaces; AMX Beacon; Cinema Quality Picture (CQP) Processing for best image quality; Crestron RoomView; DICOM simulation; Digital 3D Reform™; Direct Power-Off Function; Edge Blending Function; Free Tilt; Geometric Correction; HDBaseT; HDR10 Support; High Altitude Mode; Hollywood Quality Video Processing for best image quality; HTTP Browser Control; Keystone Correction (H=±40°, V=±40°); LAN control; Lens Memory; Lens Shift (vertical 0.65 max/-0.65 max, horizontal ± +0.25 max.); Light Source Adjustment; Manual Wall Color Correction; Multi-Screen compensation mode; NaViSet Administrator 2; Optional User Logo; OSD with 27 languages; Password Security System; PIP/Side by Side, HDMI – Input; PJ LINK; Portrait Setting; Rec2020 to Rec709 colour conversion; RS-232 Control; Seamless Switching; Stacking Function; Test Pattern; Timer-Function; UHD player support; Up to 20,000 hrs Light Source Life; Virtual Remote for direct PC control
  GREEN FEATURES
  Energy Efficiency	ECO scheduler; Intelligent Power Management; Less than 0.5W Stand-By power; Longer Light Source Life; Software scheduling; Timer-Function
  Ecological Materials	100% recyclable packaging; Downloadable manuals
  Ecological Standards	ErP compliant
  WARRANTY
  Projectors	3 years pan-European service
  Light Source	3 years or 10000h (whatever comes first)
  SHIPPING CONTENT
  Shipping Contents	IR Remote Control (RD-480E); Power Cord; Projector; Quick Setup Guide; Users Manual on CD-ROM
  OPTIONAL ACCESSORIES
  Optional Accessories	6 optional bayonet lenses; Universal Ceiling Mounts (PJ02UCMPF)
  Lenses – motorized	NP51ZL (0.53-0.65:1); NP52ZL (0.65-0.86:1); NP53ZL (0.86-1.25:1); NP54ZL (1.24-2.01:1); NP55ZL (1.98-3.95:1); NP56ZL (3.92-7.5:1)
