Logitech Tap Scheduler – Touchscreen Room Booking Display For Hybrid Workspaces (952-000091)

Description

• Description
• Specifications
• Downloads

• Room Scheduling Panel With Clear Availability Indicators



  RIGHT PLACE, RIGHT TIME
  Tap Scheduler makes it easy to see meeting details and reserve a room for ad hoc or future meetings. Easily deploy as a purpose-built scheduling panel for leading room scheduling solutions to help workers find and claim the right space.

  GREEN MEANS GO
  Quickly find an open room through colored LED lights that show availability at a distance.

  CLEAN AND EASY INSTALL
  Included mounts and clean cabling help ensure a tidy and professional setup.
  GLASS MOUNTING
  Secure Tap Scheduler while maintaining a clean look on both sides of the glass.
  MULLION MOUNTING
  Secure Tap Scheduler to a door or window frame for greater visibility using the included mount.
  WALL MOUNTING
  Place and secure Tap Scheduler anywhere on a wall.
  CABLE MANAGEMENT
  Hide cables in the wall, mullion, or in other directions, with multiple routing options.

  PURPOSE-BUILT AS A SCHEDULING PANEL
  Tap Scheduler was designed for easy viewing and usability, with a spacious screen and a sleek, unobtrusive profile. Count on Tap Scheduler for reliable performance with durable components that are built to last.

  MAKE THE MOST OF YOUR SPACE
  Easily add Tap Scheduler to a variety of meeting rooms, from phone booths to video rooms to hangout nooks, helping employees quickly find the right meeting location. Simple installations and an intuitive user experience drive fast deployment and adoption.
  PICK YOUR PLATFORM
  Enable a seamless meeting experience through Tap Scheduler and Logitech’s suite of room solutions, which integrate with Microsoft Teams®, Zoom Rooms™, and other service providers to raise the bar on collaboration.*
  SIMPLE TO MANAGE WITH LOGITECH SYNC
  With Logitech Sync, you can monitor and manage Tap Scheduler along with your other meeting room devices from one single platform.

  ENSURE BUSINESS CONTINUITY WITH SELECT SERVICE PLAN
  Remove barriers to collaboration and ensure conference rooms are ready for the next meeting. Select is a service plan beneficial for all room sizes and deployments. Optimize uptime with expert assistance within one hour, fast product replacements, and premium Sync functionality to proactively resolve issues before they impact your business. With Select, we partner with you to reduce daily management, optimize performance, and help you maximize your investment.

• DIMENSIONS
  Device-only
  Height	6.5 in (165 mm)
  Width	9.69 in (246.2 mm)
  Depth	1.12 in (28.5 mm)
  Weight	700 g (24.7 oz)
  Surface-mounted
  Height	6.5 in (165 mm)
  Width	9.69 in (246.2 mm)
  Depth	1.24 in (31.4 mm)
  Mullion-mounted
  Height	6.5 in (165 mm)
  Width	11.52 in (292.6 mm)
  Depth	1.75 in (44.5 mm)
  TECHNICAL SPECIFICATIONS
  Screen
  Size	10.1” (256.54 mm) diagonal
  Panel	IPS (In-Plane Switching)
  Resolution	1280 x 800 resolution
  Touch	Capacitive, 10 points multi-touch
  Brightness	400 nits
  Contrast	1000:1
  Anti Fingerprint	Oleophobic coating
  Viewing angle	85 degrees (U/D/L/R)
  Position angle	0 degrees (flat on mounting surface)
  General Specifications
  Integrated accelerometer
  Integrated ambient light sensor
  VESA FDMI	100 mm x 100 mm
  Cable exits	horizontal / vertical / center
  COMPATIBILITY AND CERTIFICATIONS
  Supported room scheduling solutions	Microsoft Teams Panel, Zoom Rooms Scheduling Display, Robin-Powered scheduling panel, Appspace, RICOH Spaces, Meetio scheduling panel
  Compatibility information	Logitech Compatibility
  Platforms	Logitech CollabOS platform, Logitech Sync Remote Management
  Power and Cables
  Power	Power over Ethernet (PoE), IEEE 802.3af Type 1, Class 3 device. *Requires PoE enabled network or PoE Injector and ethernet cable (Not included)
  PORTS AND INTERFACES
  Ethernet	10/100 Mbps
  WiFi	802.11a/b/g/n/ac
  Bluetooth	5.0 (inactive, reserved for future use)
  Environmental
  Operating Temperature	0 to 40°C
  Storage Temperature	-40 to 70°C
  Humidity	10-95%
  Security
  Data Encryption	AES-128
  Device Identity	Protected by device attestation
  Key Protection	Arm TrustZone
  PACKAGE CONTENTS
  Included	Logitech Tap Scheduler, Multi-surface mount (glass/drywall), Corner mount accessory, Mullion mount, Mounting hardware, Documentation
  WARRANTY INFORMATION
  Warranty	Extended warranty available, contact your reseller for availability
  PART NUMBER
  Graphite	952-000091
  White	952-000094
