Lindy 2-Port Hdmi 8K@60Hz Switch – Compact High-Bandwidth Switcher

Description

• Description
• Specifications
• Downloads

• Lindy 2 Port HDMI 8K60 Switch | 38337







  HDMI® switches are reliable solutions for controlling and switching multiple HDMI® source devices and outputting to a single display.

  The Lindy 2 Port HDMI® 48G switch is a compact, high quality solution for effortlessly switching between 2 HDMI® source devices when connected to a single display.

  Supporting HDMI® 48G signals, this switch allows for the transmission of detailed 8K Ultra High Speed resolutions, while additional support for HDR ensures video content features greater contrasts and a much wider colour gamut. This switch is perfect for a premium residential setup, eye-catching digital signage in retail settings or engaging presentations.

  This switch also provides efficient, simple switching options for the user, via an included IR remote or push buttons on the main unit. The switch can also identify the active HDMI® source device and automatically switch to this option, providing a useful solution for when the unit is required to be out of sight. HDCP 2.3 ensures the compatibility with a variety of 8K content from source devices including set top boxes, Graphics cards, Blu-Ray players and 8K HDR Media players.

  The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.

• Category	Attribute	Value
  AV Interface	Interface Type	HDMI®
  	HDMI Standard	HDMI® 2.1
  	Bandwidth	48Gbps
  	Max Resolution	7680×4320@60Hz 4:4:4 10bit
  	HDCP Support	HDCP 2.3
  	Audio	Pass-through
  	IR Support	39KHz
  	CEC Support	No
  	Serial Interface	No
  	Special Features	–
  Connectors	HDMI Input	2x HDMI Type A (Female)
  	HDMI Output	1x HDMI Type A (Female)
  	Power Port	USB Micro-B (Female)
  Physical	Dimensions (WxDxH)	90x44x14mm (3.54×1.73×0.55in)
  	Housing Material	Metal
  	Net Weight	0.0887kg (0.2lb)
  	Color	Black
  Environmental	Operating Temp	0°C – 70°C (32°F – 158°F)
  	Storage Temp	-10°C – 80°C (14°F – 176°F)
  	Humidity	5–90% RH (non-condensing)
  Power	Requirements	5VDC 1A
  Miscellaneous	Packaging Type	Carton Box
  	Package Dimensions	90x44x14mm
  	Gross Weight	0.25kg (0.5lb)
  	Warranty	2 Years
  	Certifications	CE, FCC, RoHS, REACH, Prop 65
  Box Contents	Included Items	2-Port HDMI® Switch
  		0.8m USB A to Micro-B Cable
  		Lindy Manual

• Description	Downloads
  Lindy 2 Port HDMI 8K60 Switch | 38337 User Manual	Downloads
