• LG 49VL5G-M 49″ Full HD Slim Bezel Video Wall Display

  Incredible Immersion with Ultra-Narrow Bezel


  Seamless Large Screens with Ultra-Narrow Bezel
  The ultra-narrow bezel creates a visually stunning digital wall to effectively deliver dynamic content and immerse the viewers. The large screen it generates is enough to captivate the attention of passersby.

  Image Gap Reduction
  The VL5G-M series includes an image improvement algorithm that can reduce image gaps among tiled displays when playing back videos. Objects located on the bezel boundaries are adjusted for a seamless viewing experience.


  Higher Viewing Angle
  Large screens are usually positioned higher than human-eye level, making uniform picture quality essential for video walls. The viewing angle of the VL5G-M series is high enough to display vivid colors throughout the screen with no distortion.


  Wide Viewing Angle
  It is well known that LG IPS panel technology enables better control of liquid crystals, which in turn allows the screen to be viewed from virtually any angle. Because of this, the VL5G-M series captures the attention of and captivates more viewers with lifelike colors, regardless of their viewing position.


  Easy Color Adjustment
  Depending on the content, the color temperature of the display can be easily adjusted in increments of 100K using a remote control.


  White Balance Adjustment
  In conventional video walls, white balance was adjustable only in “full-white” mode, but the VL5G-M series allows you to modify each value of grey scale to achieve more detailed and precise white balance adjustment.


  User-Friendly Menu Structure
  The menu structure has been optimized for commercial use. It simplifies approach flows and groups similar functions together, adopting a more intuitive GUI for ease of use. This way, users can avoid having to do trial-and-error when exploring desired functions and managing displays.


  Intuitive GUI
  The GUI (Graphic User Interface) is carefully designed with a four-way navigation remote control that lets users easily switch to other settings. Also, it adopts a large font for better visibility, which is necessary when users want to control displays from relatively far distances.


• Category	Specification
  Screen Size	49 inch
  Resolution	1920 x 1080 (FHD)
  Panel Technology	IPS, Direct Backlight
  Aspect Ratio	16:9
  Refresh Rate	60Hz
  Brightness	500 nits (Typ.)
  Contrast Ratio	1,000:1 (Static), 500,000:1 (Dynamic)
  Color Depth	1.07 Billion Colors
  Color Gamut	NTSC 72%
  Viewing Angle	178° x 178°
  Response Time	8ms (G to G)
  Surface Treatment	Haze 3%
  Operation Hours	24/7
  Orientation	Portrait & Landscape
  Inputs	HDMI (x2), DP In, DVI-D In, USB 2.0, RS232C In, LAN In, Audio In, IR In
  Outputs	DP Out, Audio Out, RS232C Out
  Daisy Chain	HDMI, DP, DVI-D (Input) / DP (Output)
  Bezel Width (T/R/L/B)	2.25 / 1.25 / 2.25 / 1.25 mm
  VESA Mount	600 x 400 mm
  Weight	16.9 kg (Head), 21.9 kg (Packed)
  Dimensions	1077.6 x 607.8 x 89.7 mm (Monitor)
  Power Supply	AC 100-240V~, 50/60Hz
  Power Consumption	100W (Typ.), 120W (Max), 0.5W (Standby/Off)
  BTU	341 (Typ.), 409 (Max)
  Built-in Speaker	No
  OS Version	Non-webOS
  Software Features	Local Scheduling, USB Plug & Play, Tile Mode, Cloning, HDMI-CEC, Wake on LAN
  Certifications	CB, NRTL, FCC Class A, CE, KC, Energy Star 8.0
  Environmental Rating	IP5X, RoHS, REACH, WEEE
  Operating Conditions	0°C to 40°C, 10% to 80% RH
  Accessories Included	Remote, Power Cord, RS232C Cable, DP Cable, IR Receiver, Brackets, Screws, Manual
