Kramer Dsp-1 Compact Digital Sound Processor For Audio Optimization

Description

• Description
• Specifications

• Kramer Electronics Mini Digital Sound Processor




  DSP−1 is a digital sound processor that enables the control of individual volume per input, 3−band parametric EQ, selectable HPF (high−pass filters) at 70Hz and master volume via IP. DSP−1 is a small form factor and cost−effective solution suitable for a range of audio applications.
  2–Input Mixing with Master Volume.
  3–Band Parametric Equalizer — Frequency, Q–factor & gain control per band.
  Hi–Pass Filter — Selectable HPF at 70Hz.
  Line–Level Amplifier for Audio Gain and Attenuation.
  Control with Built–In Web Page & RS–232.
  Creates & Saves Presets.
  Highly Cost Effective.
  Applications
  Classrooms or educational facilities
  Meeting rooms
  Huddle spaces
  Auditoriums

• Feature	Details
  Inputs	1 Balanced Stereo Audio (5-pin terminal block), 1 Unbalanced Stereo Audio (3.5mm Mini Jack)
  Outputs	1 Balanced Stereo Audio (5-pin terminal block)
  Ports	1 RS-232 (3-pin terminal block), 1 Ethernet (RJ-45 connector)
  Power	5V DC, 350mA
  Accessories	Power supply, mounting bracket included
  Product Dimensions	12.00cm x 7.15cm x 2.44cm (4.72″ x 2.81″ x 0.96″) W, D, H
  Product Weight	0.2kg (0.4lbs) approx.
  Shipping Dimensions	15.70cm x 12.00cm x 8.70cm (6.18″ x 4.72″ x 3.43″) W, D, H
  Shipping Weight	0.6kg (1.3lbs) approx.
