JBL Control 26C | 6.5″ Ceiling Loudspeaker Transducer, 150W, SonicGuard™ Protection
6.5″ Ceiling Loudspeaker Transducer Assembly
The Control 26C is a powerhouse ceiling speaker containing a coaxially mounted 6.5″ woofer and 3/4″ titanium-coated tweeter, able to deliver maximum sound level over a wide coverage area.
Features
Coaxially mounted 165 mm (6.5 in) woofer with butyl rubber surround and 19 mm (.75 in) titanium coated diffraction-loaded tweeter.
High power, wide frequency response and low distortion for high sound level capability.
JBL’s exclusive SonicGuard™ overload protection allows higher operational levels and improved
system reliability.
Packaged with grille, backcan and tile rails for fast installation and easy dealer stocking. -
Frequency Range 75 Hz – 20 kHz Power Rating 150W Continuous Program, 75W Pink Noise (300W peak) Nominal Sensitivity 89 dB, 1m/1W Coverage Angle 110° conical Directivity Index (DI) 4.6 (500 Hz – 4 kHz) Impedance 16 ohms Maximum SPL (1m) 107 dB (low-impedance), 113 dB peak Drivers LF: 165 mm (6.5 in) ; HF: 19 mm (¾ in) Terminations Removable 4-pin locking connector with screw terminals Dimensions (H x Dia) 210 x 252 mm (8.3 x 9.9 in) Net Weight (each) 2.7 kg (6 lbs) Shipping Weight (pair) 6.4 kg (15 lbs) Sensitivity 89 dB (100 Hz – 10 kHz) Color White Safety Agency UL1480, UL2043, NFPA90 & NFPA70 compliant, S7232/UL Listed Backcan Formed steel (included “blind-mount”) Baffle/Rim Medium impact polystyrene, UL94V-0 fire rated Ceiling Cutout Size 220 mm (8.75 in) diameter Included Accessories C-ring support plate, 2 tile rails, cutout template, paint shield, locking wiring connector Plenum Usage Yes, backcan included -
Description Downloads JBL Control 26C 6.5″ Ceiling Loudspeaker Transducer Assembly DataSheet Download
