Jbl Control 24Ct Background Music Ceiling Speaker – Low-Profile Design

Description

• Description
• Specifications
• Downloads

• JBL Control 24CT Micro | Compact 4.5″ Ceiling Speaker for Background Music & Paging

  Background Music
  The Control 24CT Micro is a compact in-ceiling speaker, providing full, high quality sound for background music and music-plus-paging systems.
  Features
  Extremely wide 150° coverage.
  Smooth frequency response.
  Includes 9 W multitap transformer for
  Shallow 4 in (100 mm) depth.
  Packaged with grille, backcan and tile rails for fast

• Frequency Range	85 Hz – 25 kHz	Power Rating	See transformer taps
  Transformer Taps	9W, 4W, 2W, 1W (& 0.5W @ 70V)	Crossover Frequency	3.5 kHz
  Maximum SPL (1m)	94 dB (top 70V/100V tap)	Sensitivity	86 dB (100 Hz – 10 kHz)
  Coverage Angle	150° conical	Input Connectors	Screw-down terminals
  Drivers	LF: 115 mm (4.5 in) HF: 12 mm (0.5 in)	Color	White
  Safety Agency	UL1480, UL2043, NFPA90 & NFPA70 compliant; UL1876 registered transformer; IEC60849/EN60849 compliant	Backcan	Formed steel (included “blind-mount”)
  Baffle/Rim	Medium impact polystyrene, UL94V-O fire rated	Ceiling Cutout Size	167 mm (6.6 in) diameter
  Included Accessories	C-shaped support plate, 2 tile support rails (2 ft & 600 mm), cutout template	Optional Accessories	MTC-24TR trim ring, MTC-24NC new construction bracket, MTC-24MR mud ring
  Plenum Usage	Yes, backcan included

• Description	Downloads
  JBL Control 24CT Micro Background Music Ceiling Speaker DataSheet	Download
