Elo E551842 I-Series 2 22″ Touchscreen for Windows 10 | Intel Celeron G4900T, 4GB RAM, 128GB SSD, FHD Display
I-Series 2 with Intel®
Elo’s I-Series 2 with Intel delivers commercial-grade computing with the capabilities, security and enterprise infrastructure of a powerful, Intel-based platform—all in a sleek, yet durable fixed tablet form factor.
Built on a modular platform and available with either 15-inch or 22-inch displays, the I-Series with Intel can be found in installations across the globe, from in-store interaction and point-of-sale to self-service, hospitality and corporate office environments. The uses are virtually unlimited.
Configure with Elo Edge Connect™
Built with versatility in mind, the Elo Edge Connect system offers a wide assortment of peripherals that seamlessly attach to the edge of the touchscreen. And you can add or swap them out later as your needs change.
Get Peace of Mind With EloCare℠
EloCare is service and support from the people who know your Elo products best. From extended warranties and on-site exchange to advance unit replacement and field services, the highly skilled Elo technical specialists will get you up and running.I-Series 2 with Intel®
Elo’s I-Series 2 with Intel delivers commercial-grade computing with the capabilities, security and enterprise infrastructure of a powerful, Intel-based platform—all in a sleek, yet durable fixed tablet form factor.
Built on a modular platform and available with either 15-inch or 22-inch displays, the I-Series with Intel can be found in installations across the globe, from in-store interaction and point-of-sale to self-service, hospitality and corporate office environments. The uses are virtually unlimited.
Configure with Elo Edge Connect™
Built with versatility in mind, the Elo Edge Connect system offers a wide assortment of peripherals that seamlessly attach to the edge of the touchscreen. And you can add or swap them out later as your needs change.
Get Peace of Mind With EloCare℠
EloCare is service and support from the people who know your Elo products best. From extended warranties and on-site exchange to advance unit replacement and field services, the highly skilled Elo technical specialists will get you up and running. -
Feature Description Part Number E551842 Enclosure Color Black Touch Technology PCAP (TouchPro® Projected Capacitive), 10-touch Processor Intel® Celeron® G4900T, 2M Cache, up to 2.9 GHz Chipset Intel® H310 Express Graphics Intel® UHD Graphics 610 BIOS AMI Memory 4GB DDR4-SDRAM, 2666 MHz SO-DIMM (1 of 2 slots used, max 8GB) Storage 128GB M.2 SATA SSD (72 TBW) TPM 2.0 Intel AMT Not supported Display 21.5″ TFT LCD (LED), 1920×1080 @60Hz, 16:9 aspect, 16.7M colors Brightness LCD panel: 250 nits / Touch: 225 nits Response Time 14 ms Contrast Ratio 1000:1 Viewing Angle 178° (H) / 178° (V) USB Ports 1 × USB 3.0, 4 × Micro USB 2.0 (for Elo Edge Connect) Ethernet 1 × RJ45 (Gigabit) Wireless Wi-Fi 802.11 a/b/g/n/ac, 2.4/5 GHz Bluetooth 5.0 Audio Ports 1 × 3.5mm line-out Speakers 2 × 2W internal Operating System Windows 10 IoT Enterprise LTSC 64-bit Power Supply External USB-C power supply, 100–240V AC, 50–60Hz, 100W Power Consumption Typical: 39W / Sleep: <5W / Off: <0.5W Dimensions 525.9 × 319.2 × 52.6 mm Shipping Box 625 × 196 × 437 mm Weight (Unpackaged) 5.2 kg Weight (Packaged) 7.0 kg Operating Temp 0°C to 35°C Storage Temp −20°C to 60°C Humidity Operating: 20–80% / Storage: 5–95% Regulatory UL/cUL, FCC, TUV, CE, CB, UKCA, NOM, RCM, VCCI, CCC, S-Mark (Argentina), BIS (India Celeron models) RTC CR2032 lithium metal battery MTBF 50,000 hours demonstrated Mounting Options 75mm / 100mm VESA mount Sealability Touchscreen sealed to sub-bezel and LCD Lock Kensington lock supported Warranty 3 years (optional extensions available) -
Description Downloads Elo I-Series 2 22″ Intel Celeron G4900T 4GB RAM 128GB SSD FHD Touchscreen Computer | E551842 DataSheet Download
