• DAHUA PHMIA135-UH 135″ 1080p All-In-One Indoor LED Foldable Display



  Convenient for transport
  Pre-assembled and can fit in an elevator (No installation required, 2-minute preparation before usage)


  Vivid color， quality details
  Powerfull AI processing, hyperchromatic technology and hyperimage processing technology, 2K/HDR，clearer, more natural and more realistic then traditional LED displays


  Obstacle-sensible and safe lifting
  Freely adjust the height, built-in obstacle sense which can stop device to go up/down when touch obstacle


  Multiple signal input
  Supports PIP and PBP, freely scale images, Supports 4 HDMI signals at the same time, support 9 control devices screen share


  Energy saving & dehumidification
  0.5W standby power consumption, multiple dehumidification function for longer LEDs life span


  Flexible dual-screen splicing
  Two all-in-one LED screens perform image signal splicing to achieve more applications


  Automatic brightness adjustment for better eye protection
  Brightness adjustable at eight levels, intelligent sensing adjustment of the light sensing probe, protecting the product and eyes


  Harman-Kardon sound
  Integrated speakers，engineered for intelligibility;Full band stereo speaker.

• Parameter	Value
  Model	DHI-PHMIA135-UH
  Pixel Pitch	1.5625mm
  Pixel Configuration	1R1G1B
  LED Type	SMD1212
  Brightness (Max)	600 nit
  Color Temperature	3200-12000K (adjustable)
  Viewing Angle (H/V)	160°/160°
  Pixel Density	409,600 dots/㎡
  Module Size (W×H)	300×168.75mm
  Display Resolution (W×H)	1920×1080
  Visible Area (H x V)	3000×1687.5mm
  Overall Size (W×H×D)	1804mm×1948mm×770mm (Folded with base)
  	3010mm×2598mm×770mm (Unfolded with base)
  Display Size	135 inch
  Cabinet Material	Die-cast aluminum
  IP Rating	IP30/ IP30
  Gray Scale	14 bits
  Contrast Ratio	6000:1
  Refresh Rate	2880~3840 Hz
  Input Voltage	AC110~220V (+/-10%)
  Input Power (Max)	2100W
  Input Power (Avg)	630W
  Installation Mode	Lifting base (standard)
  Maintenance Mode	Front Maintenance
  System Memory	4G
  Storage	64G
  Android System	Android 9.0
  Windows System	Windows 11 (optional)
  Storage Temperature / Humidity	-10℃ to 40℃ / 10% to 90% RH
  Operating Temperature / Humidity	-40℃ to +60℃ / 10% to 80% RH
  Weight	125kg ± 0.5 (Stand not included)
  	255kg ± 0.5 (Stand included)
  Control Interface	IR IN×1, Bluetooth×1, WiFi×2, RJ45×1, RS232×1
  Video Interface	HDMI1.4 IN×2, HDMI2.0 IN×2, HDMI2.1 IN×1, HDMI2.0 OUT×1
  	USB2.0×2, USB3.0×1, Type C IN 4K×1
  Audio Interface	3.5mm audio output jack Audio OUT×1
  	Optical audio output interface S/PDIF OUT×1
  	Built-in 2x20W audio
  Standard Accessories	HDMI cable, wireless screen projector, screen remote
  	control, main cable with aviation plug, lifting remote
  	control

• PHMIA135-UH : Datasheet
