Crestron Uc-Cx100-Z-Wm Advanced Flex Video Conferencing Integrator Kit

Description

• Description
• Specifications
• Downloads

• Professional Zoom Rooms Conferencing Solution for Custom Meeting Spaces

  The UC-CX100-Z-WM Crestron Flex integrator kit provides a customizable video conference solution for use with Zoom Rooms™ software. It supports up to three video displays1 (not included) and features a UC presentation transmitter, a wall mount touch screen and a UC bracket assembly.

  Native Zoom Rooms™ Software Experience
  The UC-CX100-Z-WM system features Zoom Rooms conferencing software that enables audio and video connectivity for easy collaboration and content sharing.

  Custom Room Integration
  The UC-CX100-Z-WM system provides the essential components needed to design a fully custom video conferencing space using your choice of display devices, cameras, speakers, microphones, and other AV equipment. Any Zoom Rooms software compliant USB camera and USB audio conferencing interface (or speakerphone) may be used.



  Intuitive User Interface
  With a large 10.1 in. (257 mm) capacitive touch screen display, the Crestron® wall mount touch screen (TSW‑1070‑B‑S) provides superior conferencing control in meeting rooms, huddle spaces, and executive offices. The touch screen also offers optional control of room lighting, shades, thermostats, and other equipment.2

  Simplified Deployment
  The UC Bracket Assembly provides preassembled components on one ready-to-mount bracket to simplify installation. The assembly can be mounted on a wall, or it can be attached to the rear of the display device.

  Wall Mount Options
  Using the bracket provided, the TSW-1070 is easily installed over a 2-gang or 3-gang US electrical box, or a 2-gang European or UK electrical box. A security latch option is included to deter unauthorized removal of the touch screen.

  Bring Your Own Device (BYOD)
  Conference room visitors can connect their laptop to the Crestron Flex system to use their own UC conference platform. The UC Presentation Transmitter (UC‑PR) switches to the connected laptop’s UC platform and returns to the native platform when disconnected.3 For a list of BYOD tested devices on the UC‑PR, refer to OLH Article 1000889.

  Enterprise‑Grade Security
  Crestron Flex is an enterprise‑grade solution that is ideally equipped for mass deployment throughout any sized corporate, university, medical, military, or government facility.

  Easy Provisioning and Device Management
  The XiO Cloud service is an IoT cloud based provisioning service (available separately) that enables installers and IT managers to easily deploy and manage thousands of devices. The XiO Cloud service allows for system alerts, network management and provisioning, and the pairing of a control device to the system’s UC Engine. System updates are controlled by Windows® software update.



  Key Features
  Conferencing integration solution for Zoom Rooms™ software
  Present, call, conference, and collaborate using your own device’s UC conference platform (BYOD) or the native Zoom Rooms platform
  Native Zoom Rooms touch screen UI provides a consistent user experience with simple operation and one‑touch meeting joins
  Complete kit contains a 10.1 in. touch screen, UC Presentation Transmitter, and UC Bracket Assembly
  Network management and provisioning and system alerts through the XiO Cloud® service
  Premium‑level support with Crestron Flex Care (optional)
  Enterprise-grade security – connects and communicates securely over any enterprise or SMB network
  Supports up to three video displays (not included)

• Included Components	TSW-1070-B-S	Description	10.1 in. wall mount touch screen, black
  UC-BRKT-260-P-Z-ASSY	UC Bracket Assembly for Zoom Rooms systems	Assembly Includes	UC Engine Mini PC, CAT5-USB converter, Mounting hardware
  UC-PR	UC Presentation Transmitter	CBL-4K-DP-HD-6	DisplayPort to HDMI converter cable
  CBL-CAT5E-7	Ethernet LAN cable (3)	CBL-HD-6	HDMI Interface Cable
  DM-CBL-ULTRA-PC-20	CAT6a Ethernet LAN cable	Touch Screen	10.1″ capacitive multi-touch LCD
  UI	Zoom Rooms interface	Ethernet	100 Mbps networking
  Power	PoE powered	Construction	Plastic body, glass front
  Dimensions	149 × 240 × 51 mm	Weight	730 g
  UC Engine	Intel Core processor	OS	Windows 11 IoT
  Display Output	Up to 3 displays	Resolution	1080p
  Video Input	HDMI / USB-C	Video Output	HDMI over CAT5
  HDCP	1.4 / 2.2	Device Charging	Up to 60W USB-C

• Description	Downloads
  Datasheet	Download
