• Crestron Mullion Mount Kit for TSW-770 and TSW-1070 Series, Black | TSW-770/1070-MUMK-B

  The TSW-770/1070-MUMK permits a TSW‑770, TSW‑1070, TSS‑770, or TSS‑1070 series touch screen touch screen to be attached to the mullion of an interior glass wall, window, or partition. The TSW-770/1070-MUMK mounts a compatible touch screen to the left or right of any hollow, metallic vertical mullion. Two mounting brackets are provided that allow the TSW-770/1070-MUMK to be installed in one of two configurations (side mount or front mount). Wiring is run to the touch screen from inside the mullion to create a clean, finished appearance.

  The TSW-770/1070-MUMK is ideal for mounting at the entrance to a meeting space for room scheduling applications, and it is compatible with the TSW‑770‑LB and TSW‑1070‑LB light bars to provide a clear indication of the room availability status.




  Key Features
  Permits mounting a TSW‑770, TSW‑1070, TSS‑770, or TSS‑1070 series touch screen to the mullion of an interior glass wall, window, or partition

  Ideal for mounting at the entrance to a meeting space for room scheduling applications

  Installs in either side or front mount configuration

  Wiring is run inside the mullion for a finished appearance

  Compatible with TSW‑770‑LB and TSW‑1070‑LB light bars for a clear indication of the room availability status

  Available in black or white finish

• Category	Specification	Without Touch Screen	With TSW-770/TSS-770	With TSW-1070/TSS-1070
  Construction	Housing: Aluminum, steel
  	Mounting: Attaches to the inside surface of a mullion
  Dimensions	Height	2.52 in (64 mm)	4.17 in (106 mm)	5.87 in (149 mm)
  	Width	8.97 in (228 mm)	9.30 in (236 mm)	10.63 in (270 mm)
  	Depth	1.70 in (43 mm)	2.44 in (62 mm)	2.46 in (62 mm)

• Description	Downloads
  CAD Drawing	Downloads
  Spec Sheet	Downloads
