• Biamp Parlé TCM-XA Ceiling Microphone & PoE+ Amplifier | 360° Beamtracking | AVB Conference Solution

  The Parlé TCM-XA is an AVB low-profile ceiling microphone and PoE+ (IEEE 802.3at Class 4, 30W) amplifier for use in Tesira systems.
  Comprising a network box and a ceiling microphone, each microphone includes Beamtracking technology with four 90-degree zones, providing full 360-degree coverage of the meeting space. Each network box has its own digital signal processing module and comes with an additional RJ-45 connector to add an optional TCM-XEX.
  A maximum of two microphones are permitted per network box (one TCM-X or TCM-XA with TCM-XEX). The 2-channel PoE+ amplifier includes an internal limiter, selectable power, and a burst mode to handle peak signals.
  The Parlé TCM-XA Black & Parlé TCM-XA White comply with the United States Trade Agreement Act (TAA), allowing it to be included in GSA Schedule contractors’ sales bids for the U.S. federal government.
  Key Features
  Measures 5.90 inches (150mm) in diameter
  Uses only one channel of AEC per microphone
  Network box includes DSP for Beamtracking and a PoE+ amplifier:
  Two channels
  Burst mode to handle peak loads; supports up to 40 watts (4Ω) or 30 watts (8Ω) per channel
  Software-selectable power vs. channel count
  Includes internal limiter function
  Beamtracking technology works out-of-box without any lobe aiming or room mapping
  Single cable connection via CAT5 cable
  LED mute status indicator
  Available in either black or white
  Evaluated to the requirements of UL 2043 and is suitable for use in air handling spaces
  Additional RJ-45 connection
  CE marked, UL listed, and RoHS compliant
  5-year warranty
  Compliant with the US Trade Agreement Act (TAA)

• Height	1.2 in (30 mm)	Width	6.8 in (172 mm)
  Depth	5.2 in (132 mm)	Diameter	5.9 in (150 mm)
  Weight	1.5 lbs (680 g)	Included Accessories	Optional Seismic Cable Adapter, Tile Bridge, Installation Tool, Flush Mount Kit, Plenum Box, Cat 5e Cables
  Operating Temperature	32 – 104°F (0 – 40°C)	Humidity	0–95% RH (non-condensing)
  Altitude	0–10,000 ft (0–3000 m) MSL	Power	PoE (IEEE 802.3at Class 3, 15.4W)
  Power Indicator(s)	Green/Yellow/Red LED	Network Connections	3 × RJ-45 (Switch, Microphone, TCM-XEX)
  Amplifier Channels	2 Channels	Amplifier Topology	Class D
  Burst Power Output	40W @ 4Ω / 30W @ 8Ω	Continuous Power Output	8W Single / 4W Dual Channel
  THD+N	<0.3% (20Hz–20kHz)	Frequency Response	20Hz–20kHz (±1dB)
  Dynamic Range	>85 dB	Minimum Load	4Ω
  Intermodulation Distortion	<0.3%	Crosstalk	<-90 dB @ 1kHz
  Audio Polar Pattern	Active Beamformed	SNR	>76 dB (at 1kHz, 94dBSPL A-Weighted)
  Indicators	Mute Indicator (Green/Red LED)	Digital Interface	Custom / Proprietary
  Connector	RJ-45 (6.6 ft / 2 m cable)	Max Distance	330 ft (100 m) to switch; 33 ft (10 m) to TCM-XEX
  Microphone Technology	16-Element Digital Array	Dynamic Range	92 dB (THD+N <1%)
  Frequency Response	150 Hz – 16 kHz (±3 dB)	Maximum SPL	109 dB (<1% THD)
  TAA Compliant	Yes	Certifications	FCC Part 15B, CE, UL/C-UL, RoHS, UL 2043 (air handling)
