Description

• Description
• Specifications
• Downloads

• Biamp DX-IC8-W Wired 175 W 2-Way Loudspeaker White




  Key Features
  Zoom Rooms Certified
  High intelligibility with exceptional uniform coverage
  Fast installation with SpringLock mounting clamps
  Higher output than typical ‘high-ceiling’ 8-inch ceiling speakers
  Attractive edgeless magnetic grille design
  Conduit knockouts on the input cover meet Chicago plenum air space requirements
  5-year warranty
  The Desono DX-IC8 rewrites the cost-to-performance equation for high-end ceiling loudspeakers. Able to fulfill a wide variety of needs, the DX-IC8 exceeds the performance of competing high-ceiling models. Foreground music, high-level paging, and augmentation of large music systems as a delay or fill speaker in ancillary zones are all within the capability of this versatile performer. It is ideal for high ceiling applications.
  Uniform voicing among the Desono DX product family makes for an easy match to the other models in the series, while a host of design innovations set the DX-IC8 apart from other products in its size and price range. Featuring a genuine coaxial design with separate magnets for the LF and HF drivers, the DX-IC8 exhibits reduced distortion and industry-leading sensitivity permitting 3 dB to 6 dB greater output level, while requiring half the amplification power of competing products.

• Category	Specification	Description
  GENERAL	Depth	8.51 inches (216 mm)
  	Diameter	13.43 inches (341 mm)
  	Cutout Diameter	12.20 inches (310 mm)
  	Weight	15.6 lbs (7.08 kg)
  	Finish	RAL Color: White RAL 9016
  ENVIRONMENTAL	Operating Environment	Indoor
  POWER	Power	175W Continuous, 700W Peak
  LOUDSPEAKER	Loudspeaker Type	Two-way 8-inch ceiling loudspeaker
  	Operating Range	75 Hz – 20 kHz
  	Transformer	70V: 120W, 60W, 30W, 15W; 100V: 120W, 60W, 30W
  	Sensitivity	(1W/1m) 93 dB
  	Dispersion	115° conical
  	Drivers	LF 1 x 8″, HF 1 x 1.25″
  AUDIO	Impedance	7Ω
  	Maximum Output	Max Output @1m: 116 dB, 126 dB Peak
  CERTIFIED SOLUTIONS	Zoom	Zoom Certified
  COMPLIANCE	Certifications	UL1480, UL2043, CSA62368-1, NFPA70, NFPA90

• Description	Downloads
  Biamp DX-IC8-W Wired 175 W 2-Way Loudspeaker White | 910.0106.900 DataSheet	Downloads
