• Biamp Desono DX-S8 Two-Way High Output Coaxial 8-inch Surface Mount Loudspeaker ClickMount Black




  DX-S8-B
  The Desono™ DX surface mount loudspeakers provide high efficiency, high output, high intelligibility and low distortion in an attractive design. These loudspeakers install quickly and have the same components and voicing as the DX ceiling loudspeakers. The DX surface mount loudspeakers are equipped with a built-in 70 V/100 V autoformer and low impedance input.
  For larger installations, the 8″ coaxial DX-S8 provides higher sound pressure levels, higher sensitivity and greater bass extension. The DX-S8 also easily outperforms competitive 10″ format loudspeakers. With a modern appearance that merges well in most environments, combined with weather-resistant capability suitable for direct outdoor use, the DX-S8 can be used in a wide variety of speech and music applications.
  5-year warranty

• Category	Specification	Description
  GENERAL	Height	15.16 inches (385 mm)
  	Width	10.04 inches (255 mm)
  	Depth	10.24 inches (260 mm)
  	Weight	17 lbs (7.71 kg)
  	Finish	RAL Color: Black RAL 9017
  ENVIRONMENTAL	Operating Environment	Indoor
  POWER	Power	175W Cont., 700W Peak
  LOUDSPEAKER	Loudspeaker Type	Two-way 8-inch surface mount loudspeaker
  	Operating Range	62 Hz – 18 kHz
  	Transformer	70V: 120W, 60W, 30W, 15W; 100V: 120W, 60W, 30W
  	Sensitivity	(1W/1m) 94 dB
  	Dispersion	(H x V) 110° x 110°
  	Drivers	LF 1 x 8″, HF 1 x 1.25″
  AUDIO	Impedance	7Ω
  	Maximum Output	Max Output @1m: 116 dB, 126 dB Peak
  CERTIFIED SOLUTIONS	Zoom	Zoom Certified
  COMPLIANCE	Certifications	CSA 62368-1

• Description	Downloads
  Biamp Desono DX-S8 Two-Way High Output Coaxial 8-inch Surface Mount Loudspeaker ClickMount Black | 910.0109.900 DataSheet	Downloads
