• B-Tech Motorised Height Adjustable Flat Screen Trolley – For screens up to 86″

  The BT8568 is a mobile solution designed to mount large screens up to 86″. Electronic height adjustment enables effortless raising and lowering of the screen via a wired control panel, with an adjustment range of up to 650mm. This trolley is ideal for mounting interactive touchscreens into education and corporate environments and is capable of supporting loads up to 100kg. The mount has a modern design and features a simple hook-on installation for quick and easy screen fitting and incorporates an adaptor plate for the fitting of AV accessory shelves.




  Features
  Easy to use motorised height adjustment allows the mounted screen to be positioned at the
  ideal height for the user
  Ideal for use with large touch screens and interactive displays
  Supplied with a wired control console
  Automatic auto-stop when resistance is felt
  Interface arms include levelling screws to adjust the height of the screen
  Safety screws help prevent unauthorised removal of the screen
  Non-marking locking / braked castors included
  TUV, CE and UKCA certified
  Simple hook-on screen installation
  All mounting hardware included

• Specification	Details
  Recommended Screen Size	55″ (140cm) to 86″ (218cm)
  Max Load	100kg (220lbs)
  Dimensions (H x W x D)	H: 1360-2010mm (53″-79″)
  	W: 1255mm (49″)
  	D: 740mm (29″)
  VESA® & Non-VESA Fixings	Up to 1000 x 600
  Height Adjustment Range	Up to 650mm (25.6″)
  Height Adjustment Speed	32mm per second

• Description	Downloads
  Specification Sheet	Downloads
  Installation guide	Downloads
  Technical Drawings	Downloads
