Adastra 952.714Uk Two-Way 100V Indoor Ceiling Speaker

Description

• Description
• Specifications
• Downloads

• Adastra BC5V-W | 5.25″ 2-Way Wall Speaker, 30W 100V, White

  Industry standard 100V indoor speakers with ABS enclosures and a powder coated steel grille grille. Wall or ceiling surface mounting via the adjustable steel bracket. The trapezoidal design allows for the enclosures to be mounted neatly into corners or angled for directional coverage. Main drivers have high quality coated paper cones for full-sounding low and mid-range frequencies, ideal for music playback and clear voice announcements.
  Rotary selector switch for 100V line tappings or 8 Ohms operation
  2 way speaker system with crossover network
  Wall mounting bracket supplied
  Alternative M6 threaded mounting points
  Spring terminal connection
  Supplied singly
  In the Box
  BC-series indoor 100V PA speaker
  Wall-mounting bracket
  2 x cap screws

• Weight	2.38 kg	Dimensions (W x H x D)	180 x 235 x 175 mm
  Impedance (100V)	333, 500, 1k, 2k Ohms	Tappings	30W, 20W, 10W, 5W + 8 Ohms
  SPL @ 1W/1m	89 dB	Power (RMS, 8 Ohms)	45 W
  Power (Max, 8 Ohms)	90 W	Frequency Response	100 Hz – 20 kHz
  Tweeter	25 mm (1″) balanced dome	Woofer	130 mm (5.25″) reinforced paper cone
  Colour	White	Model	BC5V-W
  Connection	Spring terminals

• Description	Downloads
  Adastra 952.714UK 2-Way 100V Indoor Speaker User Manual	Download
